AECO Chassis Mount Copper RCA Sockets 1 Pair ARJ-4045G

Mechanical structure:
Signal contact part is assembled inside the body together with PTFE.
POM covers around the body to isolate the metal panel.
The jack is to be assembled from inside of the panel through the opening, tighten by washer and pentagram nut
This product is suitable for 10 mm circular opening of the panel
This product is suitable for the maximum 3.5 mm thickness of the panel
The torque for the nut on this product can be reach to maximum 8 (lb-in)
Material:
Contact Pin: Copper (#C1100 / copper contains over 99.5%)
Grounding: Tellurium Copper (#C14500 / copper contains over 99%)
Insulator: PTEF (White)
Shell: POM (Black)
Washer: PE(White / Red)
Nut: Brass alloy (#C3604)

Electrical Characteristics:
Contact resistance < 0.3 mOhm (It was test by ARP-4043/4045.)

Dimension：
Biggest OD 15.0mm
Total Length 29.0m

​

Packing:
Vacuum Bag(2Pcs/1Set)
